Description
PROCESSED ACTIVE MONITOR 350W + 100W RMS – 128DB SPL
- 2-way bi-amplified system in Bass-Reflex2-way bi-amplified system in Bass-Reflex
- Polypropylene enclosure with integrated handle except J 5A/5
- 2 x M10 anchoring points (15A, 12A, DJ 15A), 2 x M6 suspension points (8A, 5A)
- 25mm (1”) HF custom AF compression driver (15A, 12A, 8A, DJ 15A)
- 90°H x 60°V constant directivity horn (15A, 12A, 8A, DJ 15A)?
- 320mm (12’’) custom woofer with improved efficiency and linearity
- 350Wrms class D amplifier for LF and 100Wrms for HF.
- High efficiency switch mode power supply
- On-board Digital Signal processing with dynamic equalizations and protections for high SPL and high reliability.
- 4 DSP preset for maximum acoustical flexibility
Technical Specifications
Code:37714
Configuration:2 way
Built-in amplifier LF/HF:350/100 W RMS
Frequency response:50Hz – 20KHz -6dB
Low Frequency woofer:12 – 2 coil inch
High Frequency driver:1 -1 coil inch
Maximum SPL cont/peak:124/128 dB
Dispersion:90° x 60° HxV
Input impedance:22 Kohm
Input connector:XLR – jack with loop
Power cord:5 / 16.4 m/ft
Net Dimension (WxHxD):410x663x387 – 16.14×26.10×15.23 mm/inch
Net Weight:13.7 / 30.2 Kg/lb
Transport Dimension (WxHxD):495x740x475 – 19.48×29.13×18.70 mm/inch
Transport Weight:16.8 / 37.03 Kg/lb
