Description
Amplifier/Matrix 4x500W @4 ohm / 2x1000W (100V/Bridge@8 Ohm). DSP. Wi-fi control, Ethernet. GPIO
Compact four-channel installation amplifier (up to 500W per channel at 4 ohms) or 1000W per output from its two 100V/Bridge@8 Ohm line outputs. Digital signal input and output for easy, conversion-free interconnection. Dedicated DSP with standalone Wi-Fi connectivity and full control. Ethernet and GPIO.
- 4x500W @ 4Ohm, 2x1000W @ 4Ohm Bridge, 2x1000W (100V/Bridge@8 Ohm)
- Control from your own WAP Access Point without the need to download software
- Internal DSP matrix with 4 mono or 2 stereo inputs, output to 2 or 4 zones and S/PDIF link to connect with other amplifiers
- Class D Amplifier
| Channels | 4 LoZ / 2 HiZ |
| Low impedance power | 4 x 500W @ 4 Ohm / 4 x 400W @ 8 Ohm |
| Power 100V | 2 x 1000W |
| Audio Input | 4 x Euroblock (balanced) or 4 x RCA (unbalanced) 1 x Digital S/PDIF (RCA)/ 4 x Euroblock (balanced) or 4 x RCA (unbalanced) 1 x Digital S/PDIF (RCA) |
| Frequency Range | 20Hz-20kHz |
| S/R ratio | >106 dB |
| Crossover | Butterworth, Bessel, Linkwitz-Riley |
| Equalization | Parametric 10 bands, LPF, HPF, BPF |
| Input power supply | AC 100/240V, 50/60Hz, 75W |
| Dimensions | 483 x 88 x 319mm |
| Weight | 3.4kg |
| Connectors | Euroblock/RCA Inputs, Euroblock Speaker Output, Euroblock GPIO, RJ45, RCA S/PDIF IN/OUT |
