Description
PASSIVE SOUND REINFORCEMENT 300W / 8 OHM – 119DB SPL
- 1 x 6” (1.25” VC) custom made LF woofer with rubber surround
- 1 x 1” HF dome tweeter
- 6 x M5 threaded rigging points
- 2-way, passive sound reinforcement systems
- Custom designed LF woofers, Made in Italy
- Custom designed HF dome tweeter, Made in Italy
- Crossover networks equipped with 4 x Euroblock speaker terminals; factory preset for optimal line transformer installation
Technical Specifications
Code:36251
Configuration:2 way
Recommended amplifier:300 W RMS
Long Term power:150 W
Short term power:600 W
Nominal impedance:8 ohm
Frequency response:60Hz – 22KHz -6dB
Low Frequency woofer:6.5 – 1.5 coil inch
High frequency driver:1 – 1 coil dome inch
Sensitivity (@1W/1m):91 dB
Maximum SPL cont/peak:116/119 dB
Dispersion:100° HxV
Crossover Frequency:2,5 KHz
Recommended HP filter:45Hz – 24dboct
Recommended external filter:
Input connector:4 x Euroblock
Net Dimension (WxHxD):216x360x216 – 8.5×14.17×8.50 mm/inch
Net Weight:5.5/12.1 kg/lb
