Description
- Bracket included
- Grey or black ABS loudspeaker
- 2 way bass reflex
- 5” woofer and 0.75” tweeter
- 100V line transformer(Multi Tapp)
- Frequency response @-10dB 85Hz-20kHz
- Dispersion HxV 100°x100°
- High-pass filter recommended 55Hz-24dB/oct
- 30W/60W nominal/maximum power
- 50W/100W nominal/maximum power
- Setting: 15/25/40/50W/8ohm
- Sensitivity 89dB
- Max SPL 109Db
Technical Specifications
Code:29223 BT / 32368 WHT
Configuration:2 way
Recommended amplifier:60 W RMS
Long Term power:30 W
Short term power:120 W
Nominal impedance:8 ohm
Frequency response:85Hz – 20KHz -6dB
Low Frequency woofer:5 inch
High frequency driver:
Sensitivity (@1W/1m):87.5 dB
Maximum SPL cont/peak:106 dB
Dispersion:120×120 HxV
Crossover Frequency:
Recommended HP filter:55Hz – 24dBoct
Recommended external filter:
Input connector:Euroblock
Net Dimension (WxHxD):168x240x180 mm/inch
