Description
PASSIVE REINFORCEMENT SPEAKER 500W / 8OHM – 130DB SPL
- 2-way, bass reflex design
- Digital Signal Processor with graphic display
- 15 mm (0.59”) birch plywood scratch resistant enclosure and internal bracing
- High efficiency switch mode power supply
- Control Panel features balanced XLR/Jack input, XLR LINK OUT, 2 x Volume, RCA Stereo input, DSP display with rotative encoder and push
- Built-in passive crossover with soft-trip protection for the LF woofer and HF driver
- Speakon NL-4 IN and LINK OUT connectors
Technical Specifications
Code:40680
Configuration:2 way
Recommended amplifier:500 W RMS
Long Term power:250 W
Short term power:1000 W
Nominal impedance:8 ohm
Frequency response:50Hz – 18KHz -6dB
Low Frequency woofer:15 – 2.5 coil inch
High frequency driver:1 – 1.7 coil inch
Sensitivity (@1W/1m):99 dB
Maximum SPL cont/peak:126/130 dB
Dispersion:80° x 50° rotatable HxV
Crossover Frequency:1.4 KHz
Recommended HP filter:HP 40 Hz – 12-24dB/oct
Recommended external filter:FBT DLM26
Input connector:2xSpeakon
Net Dimension (WxHxD):427x765x420 / 16.81×30.11×16.53 mm/inch
Net Weight:24.5/54.01 kg/lb
